QCharge Introducing The UltraPower QAC2-BC Line EV Charger Unmatched Power and Performance, 40A, 48A and 80A(Single Port) (40A) 產品型號: 5059901

Elevate your charging experience with the UltraPower EV Charger, designed to meet the

demanding needs of both commercial and residential environments. Featuring powerful

charging capabilities of 40A and 48A, this charger delivers unrivaled performance and

reliability.

Product Specifications:

Application: Commercial

Voltage & Wiring: Nominal 208-240V AC single-phase

Frequency (Hz): 60 Hz

Current Output: 40A Max / 48A x 2 Max

Charging Connector: Type 3R

Electrical Protection: Over current, Under voltage,Over voltage, Over temperature, Surge

protection, Short circuit, Ground fault

User Interface: 5” LCD Display, 1x Physical Button

Network Interface & Connectivity: Ethernet, WLAN, Cellular, Wi-Fi

User Authentication: RFID Card Reader, Mobile App

Data Protocol: OCPP 1.6J, OCPP 2.0.1

Operation Temperature: -30°C ~ 50°C / -22°F ~ 122°F

Storage Temperature: -40°C ~ 70°C / -40°F ~ 158°F

Working Humidity: 5% ~ 95% without condensation

Mounting Type: Wall Mount (default) / Floor post (optional accessory)

Enclosure Rating: IP65 / IK10

Charging Cable Length: Customizable

Dimension (H x W x D mm): 245mm x 365mm x 121.5mmWeight: 7.7Kg

Mobile App: iOS / Android compatible

Certification: UL Compliant, UL2524, UL2231-1/2, ETL, FCC

Charger Configuration: DIPSwitch / Web Portal

Meter IC: ISO 14443A/B, APP for Measuring & Load Balancing

Experience the power and performance of the UltraPower EV Charger, the ultimate solution

for all your charging needs. Efficient, reliable, and packed with smart features, it's the perfect

choice for commercial and residential charging environments alike.
